Time Activated Relay 16 Channel with Wireless Interface

Wireless Time Schedule Relay with 802.15.4 Interface

Wireless Time Activated Relay

All The Features You Need...

  • 16 Relays Installed on Circuit Board
  • Control Relays based on Time Schedule
  • Accurate Machine-Manufactured Design
  • Reliable Sturdy Design
  • Onboard 802.15.4 Interface Module
      - Requires 802.15.4 Modem
  • Modem Mounts as a Virtual COM Port on Computer
  • Supports Daylight Savings Time
  • Sync Time with PC or Manually Set Time
  • Base Station Software
     - Point & Click Interface
     - Use to Configure Time Schedule
     - Manually Trigger Relays

Wireless Time Activated Relays
Set Time Schedule to Trigger Relays

Our Time Relays are equipped with firmware built into the board that will allow you to setup a time schedule to trigger relays.  The Time Relay series has an integrated Real Time Clock to control relays based on a time schedule (the board knows what day & time it is).  These relays use a 802.15.4 wireless modem connected to the USB port of your computer to communicate.  The modem supports any available COM port at any standard baud rate, allowing you to setup the time schedule & upload it to the board.  Once stored, the computer is no longer needed, the relays will activate according to your schedule.

Time Schedule Control

Events are scheduled times when a relay or group of relays are turned on or off.  They are defined by the user first by time: Year, Month, Day of Month, Day of week, Hour, Minute, and Second.  You have the ability of switching relays on or off at very specific times.  You can add up to 1000 Events to the list.

Time Relay - Without Having to Learn Programming
These 16-Channel Time Activated Relays con trigger
relays according to a time schedule!
Time Activated Relay You Can Count On!

Also Available:

Timer Software

Relay Timer
Relay Timer R2X Programmable Timer
For applications where time must match a computer or server use Relay Timer.

Relay Timer is software that uses a computer's time!
Relay Timer Software

Selecting The Wireless 802.15.4 Interface

USB Relay ZUSB ModuleBy selecting the 802.15.4 interface you will be sending commands through a modem connected to the USB port of your computer.  Boards on this page are equipped with a 802.15.4 communications module that adds wireless communications to the board.  Time configurations can be uploaded to the board through a wireless wireless connection using the included Base Station Software.

Selecting a Wireless Time activated Relay

Below you will find the 16-channel Wireles Time Activated Relays that are available.  The difference being the amperage of the relays installed and the type of relay.  Choose the controller that fits the amperage you are switching.  You will find SPDT relays in the 5, 10 and 20 amp versions and an SPST version in 30 amp.  For more information on selecting the correct relay for your application see Choosing a Proper Amperage.

Easy Board Selection

Find the board you need by using the interactive menu to he right.  Hover over the Button and select the number of relays you want installed and then select the computer interface you need.  Once there simply select the board with the correct amperage for the item you are switching.

Wireless Time Schedule Relay with 802.15.4 Interface

Displaying 1 - 2 of 2 Products in this Category.
Sort By:

Display Page:     ( 1 )

Sort By:

Display Page:     ( 1 )
