National Control Devices: XSC Long Range Wireless Controller 24-Channel 10 Amp SPDT + 8-Channel 8/10-Bit A/D

ZADSR2410PROXR_XSC XSC Long Range Relay

XSC Long Range Wireless Controller 24-Channel 10 Amp SPDT + 8-Channel 8/10-Bit A/D

XSC has the capabilities to cover distances of up to 15 miles with an outside antenna installed!

Control this Device Over the Internet

Signal Switch Compatible

XSC Long Range Wireless Controller 24-Channel 10 Amp SPDT + 8-Channel 8/10-Bit A/D

$524.00/ea

The latest version of the ProXR Series have interchangeable communications modules that can be swapped at will. Simply disconnect all power from the board and pull off one module and replace it with another.

Long Range XSC ProXR Series at a Glance

XSC allows for Long Range Communications with your choice of 1 mile or 15 miles range modules
Expandable to control up to 256 Relays using the XR Expansion Port

16 Background Timers Can be Assigned to Any of the Relays while Processing Your Commands

Server Reboot, Watchdog, & Keep Alive Duration/Pulse Timing Command Set

Add Relays to this Controller is your Needs Ever Grow
Control One Relay at a Time or All 256 Relays at Once with Manual and Automatic Refreshing Command Set
CPU Status LEDs Show Command Processing Activity
8 Channels of 8/10 bit A/D Inputs
